LDM(Logical Disk Manager) MetaData Partition

LDM METADATA PARTITION

GPT GUID: 5808c8aa-7e8f-42e0-85d2-e1e90434cfb3

MBR partition ID: None

The LDM Metadata partition is a 1-megabyte hidden partition that stores the dynamic disk database, which contains information about all dynamic disks and volumes installed on the computer.



LDM DATA PARTITION

GPT GUID: af9b60a0-1431-4f62-bc68-3311714a69ad

MBR partition ID: 0x42

The LDM Data partition acts as a container for dynamic volumes. Individual dynamic volumes do not contain entries in the GUID partition entry array.



docs.microsoft.com/en-us/previous-versions/windows/it-pro/windows-server-2003/cc758035(v=ws.10)

https://docs.microsoft.com/en-us/windows/win32/api/winioctl/ns-winioctl-partition_information_gpt



The location of the database is determined by the partition style of the disk.

   - On MBR disks, the database is contained in the last 1-MB of the disk.

   - On GPT disks, the database is contained in a 1-MB reserved (hidden) partition(LDM Metadata partition).

docs.microsoft.com/en-us/previous-versions/windows/it-pro/windows-xp/bb457110(v=technet.10)?redirectedfrom=MSDN





How Dynamic Disks and Volumes Work: Storage Services | Microsoft Docs



MBR에서는 LDM metadata를 저장하는 공간은 partition이 아니므로 표시되지 않습니다.

(bootice의 sector edit - unassigned space에서 data를 볼 수 있습니다)

GPT에서는 MSR의 첫 1MB를 차지합니다(Microsoft 문서의 그림과는 위치만 다름).



할당되지 않은 공간...1MB? doyaji-bw.tistory.com/33



https://dl.acronis.com/u/pdf/AcronisBackupLS_11.7_userguide_ko-KR.pdf

https://docs.microsoft.com/en-us/windows/win32/fileio/basic-and-dynamic-disks

https://en.wikipedia.org/wiki/Logical_Disk_Manager

docs.microsoft.com/en-us/previous-versions/windows/it-pro/windows-server-2003/cc739412(v=ws.10)#mbr-disks-that-do-not-have-space-for-the-dynamic-disk-database
